AP200M2-3WIRE AVFI AIRPOWER LIMIT SWITCH
- Features:
- Rotary position indication device
- Has a mechanical switch to sense mechanical position(on/off) of valve for remote PLC or PC indication
- Visual indicator for local detection
- Type 4, 4X, IP67
Technical Information
| Product Code | Description |
|---|---|
CONDUIT ENTRIES | Two ½” BSPP |
TERMINAL STRIP CONTACTS | 8 |
AMBIENT TEMPERATURE | -25°C to -85°C |
MOUNTING BRACKET | 1MB – 1.0: 30 x80 H:20, 30 (Carbon steel) |
OPERATING VOLTAGE (SENSOR) | Max: 5A125*250 VAC |
Materials
| Description | Material |
|---|---|
ENCLOSURE | Die-casting aluminum dichromate conversion with polyester powder coating and O-ring sealed |
O-RINGS | Buna N |
FASTENERS | Stainless Steel |
SHAFT | Stainless steel Namur |
